FEATURES:
  ★High stability of capacitance and DF versus temperature and frequency
  ★Special serial construction for high voltage and long-term ability
  ★High pulse rise rate (du/dt)and suitable for large current circuit

   APPLICATIONS:
  ★Most suitable for high voltage and pulse in the horizontal resonance circuit of colour TV set.


   SPECIFICATIONS:

  ※DIELECTRIC: Polypropylene film
  ※ELECTRODES: Aluminum foil as outer electrodes and vavuum evaporated metal layer as inner series electrode
  ※COATING: Epoxy resin coating
  ※LEADS: Radial leads of tinned wire
  ※REFRENCE STANDARD : IEC384-17;GB14579-1993
  ※CLIMATIC CATALOGUE: 40/85/21
  ※CAPACITANCE VERSUS RATED VOLTAGE (UR):0.001uF-     2.5uF/1000VDC;
  ※CAPACITANCE TOLERANCE: J=±5%
  ※DISSIPATION FACTOR(TANGENT OF LOSS): DF≤0.1%(at 20`C,1KHz)
  ※VOLTAGE PROOF:2.0*Ur(1 minute at 20`C)

  ※Through electric current:80-100A
  ※INSULATION RESISTANCE: C≤0.10uF IR≥30000MΩ；(1 minute at 20`C and RH≤65%)
  ※ENDURANCE: 1000 hours with 125% of rated voltage at 85`C.
                                   After the test:
                                  C/C≤10%;DF≤0.3%
                                   IR≥50% of the specified value(20`C 1KHz)
